Introduction

The Aqua-Pro Reef aquarium range has been professionally designed for today’s reefkeepers. These systems are suitable for beginners right through to those at the cutting edge of the hobby, and combines practicality with a modern premium finish. The design allows for marine hobbyists to choose and add their own equipment, building a bespoke sump-based saltwater system which is tailored exactly to their own methods, taste, experience and budget.

With five different models to choose from and 11 colour finishes you can find the perfect solution for your home reef.

Aqua-Pro Reef aquariums are made from ultra clear low iron glass and include a host of features as standard including central overflow weir, multichambered sump with moveable baffles, top up reservoir and full pipework set.

Aquarium Highlights

• Made from ultra clear low iron glass, with no strapping and fully polished edged to provide the perfect view of your home reef.
• Central weir box to allow for a full unobstructed view into the aquarium from both sides. Featuring a removeable weir comb for easy cleaning and maintenance.
• Black vinyl background pre-fitted to the rear of the aquarium to make your aquarium inhabitants stand out.
• Twin adjustable flair nozzle outlets fitted as standard to allow water returned from the sump to be directed in multiple directions.
• Two overflow pipe system to allow for safe silent running.
• Basemat pre-fitted to the bottom of the aquarium.
• Black silicone joints.
• Ideal for use with the D-D Slimline lighting bracket and Jump Guard mesh aquarium covers.

Sump Highlights

The Aqua-Pro Reef aquariums come with a multi chamber sump with freshwater top up reservoir.

To suit as many different filtration options as possible the Aqua-Pro Reef sumps not only have separate sections but also adjustable baffles. These allow water heights to be customised and changed as needed. This can be especially useful if setting up a refugium where you may want to run a deeper water depth than is normally offered or want to set the perfect running height for your protein skimmer without having to use stands or messy solutions to raise the unit off the bottom of the sump. Simply loosen the two fixings slightly, slide the baffle to the desired height and then tighten back up. This is easy to do even with the aquarium running and no tools are required.

• 6mm + 8mm glass construction.
• Height adjustable acrylic baffles for water depth adjustment.
• Included freshwater top up reservoir.
• CNC cut dividers glass dividers.
• Pre-fitted foam base mat.
• Polished and bevelled glass edges.

Wooden Cabinet

• Clean contemporary finish with sleek lines to match the style of the Aqua-Pro Reef aquarium.
• Fully prebuilt with the option of 11 different colour finishes to match and compliment any home decor.
• Adjustable soft close hinges fitted as standard.
• Quick release doors to provide full access of maintenance.
• Large ventilation space allowed in the back of the cabinet to help prevent moisture build up inside the cabinet.
• Aircraft grade aluminium frame with adjustable feet as standard on the 1500 and 1800 models, also available as an option for the 1200.

Aquaframe

With the larger aquariums comes more weight and so the 1500mm and 1800mm cabinets are fitted as standard with an integrated metal frame. There is an option for a metal frame on the 1200mm model.

The pre-assembled AquaFrame cabinets are made from an aircraft grade aluminium section which is cut and fastened together by special custom stainless steel brackets and high strength rivets.

The Aquaframe system allows you to future-proof your aquarium by enabling you to change the cabinet colours at any time, to match a change in decor, without buying a brand new cabinet. Choose from our range of 11 stylish cabinet finishes.

• Corrosion resistant frames made from aircraft grade aluminium
• Easily swap the cabinet panels without buying a new cabinet
• Pre-assembled
• Choose from 11 cabinet finishes
• Adjustable feet, fully waterproof base board
• Soft-close, push open doors.
• Industrial strength fittings



System Specification

  Aqua-Pro Reef Models
  600 CUBE 900 1200 1500 1800
Tank Specification
 Length 60cm / 23.6" 90cm / 35.4" 120cm / 47.2" 150cm / 59.1" 180cm / 70.9"
 Width  60cm / 23.6" 50cm / 19.7" 60cm / 23.6" 60cm / 23.6" 60cm / 23.6"
 Height 60cm / 23.6" 60cm / 23.6" 60cm / 23.6" 60cm / 23.6" 60cm / 23.6"

 Glass Thickness 10mm 12mm 15mm 15mm 19mm
 Low Iron Ultra Clear Glass
 Display Tank Water Volume  184 Litres 228 Litres 370 Litres 465 Litres 547 Litres
 Weir Dimensions (Including Comb) 24 x 10 x 57.3cm 24 x 10 x 57.3cm 24 x 10 x 58cm 24 x 10 x 58cm 24 x 10 x 57.7cm
 Removeable Weir Comb
 Central Weir
 Pre-fitted Basemat
 Black Vinyl Background

Sump Specification
 External Length 50cm / 19.7" 80cm / 31.5" 80cm / 31.5" 90cm / 35.4" 80cm / 31.5"
 External Width  38cm / 15.0" 35cm / 13.8" 45cm / 17.7" 45cm / 17.7" 45cm / 17.7"
 External Height 40cm / 15.7" 40cm / 15.7" 45cm / 17.7" 45cm / 17.7" 40cm / 15.7"

 Skimmer Chamber Dimensions 24 x 18cm 25 x 33.8cm 25 x 43.8cm 30 x 43.8cm 35 x 43.8cm
 Reactor / Refugium Chamber Dimensions 24 x 18cm 21.6 x 33.8cm 24.1 x 43.8cm 26.6 x 43.8cm 27.2 x 43.8cm
 Return Pump Chamber Dimensions 24 x 18cm 15 x 33.8cm 15 x 43.8cm 15 x 43.8cm 15 x 43.8cm
 Top Up Reservoir Dimensions 24 x 18cm 15 x 33.8cm 12.5 x 43.8cm 15 x 43.8cm 28.8 x 43.8cm

 Glass Thickness 6mm and 8mm 6mm and 8mm 6mm and 8mm 6mm and 8mm 6mm and 8mm
 Adjustable Height Baffles
 Minimum Sump Water Volume 22 Litres 36 Litres  49 Litres 55 Litres 60 Litres
 Maximum Sump Water Volume 32 Litres 57 Litres 77 Litres 86 Litres 93 Litres
 Skimmer Chamber Water Depth Adjustable 20 - 30cm Adjustable 20 - 30cm Adjustable 20 - 30cm Adjustable 20 - 30cm Adjustable 20 - 30cm
 Reactor / Refugium Chamber Water Depth Adjustable 16 - 26cm Adjustable 16 - 26cm Adjustable 16 - 26cm Adjustable 16 - 26cm Adjustable 16 - 26cm
 Top Up Reservoir Volume 16.6 Litres 19.5 Litres 23.8 Litres 28.5 Litres 48.4 Litres
 Top Up Reservoir  Built Into Sump Built Into Sump Built Into Sump Built Into Sump Stand Alone
 Pre-fitted Basemat

Pipework Specification
 Main Overflow Pipe 40mm 40mm 40mm 40mm 40mm
 Emergency Overflow Pipe 40mm 40mm 40mm 40mm 40mm
 Return Stand Pipe 25mm 25mm 25mm 25mm 25mm
 Twin Flare Nozle Outlet
 Return pipe Hosetail 19mm 19mm 19mm 19mm 19mm

System Specification
 Total Minimum Volume 206 Litres 264 Litres 419 Litres 520 Litres 607 Litres
 Total Maximum Volume 216 Litres 285 Litres 447 Litres 551 Litres 640 Litres
 Polished Glass Edges
 Black Silicone Joints
 Recommended Return Pump Size 1500-2000 LPH 2000-3000 LPH 3000-4000 LPH 3000-4000 LPH 4000-5000 LPH

Cabinet Specification
 Length  60cm / 23.6" 90cm / 35.4" 120cm / 47.2" 150cm / 59.1" 180cm / 70.9"
 Width 60cm / 23.6" 50cm / 19.7" 60cm / 23.6" 60cm / 23.6" 60cm / 23.6"
 Height 90cm / 35.4" 83cm / 32.7" 90cm / 35.4" 90cm / 35.4" 90cm / 35.4"

 Wooden Cabinet Option
 Metal Frame Cabinet Option
 Adjustable feet *
      *Metal frame option only

Recommended Equipment

  Aqua-Pro Reef Models
  600 CUBE 900 1200 1500 1800
Recommended Equipment
 Return Pump Jecod DCP2500 Jecod DCP2500 Jecod DCP4000 Jecod DCP4000 Jecod DCP6500
 Heater 250W D-D Titanium 350W D-D Titanium 650W D-D Titanium 650W D-D Titanium 2 x 350W D-D Titanium
 Protein Skimmer Deltec 400i Deltec 400i Deltec 600i Deltec 1000i Deltec 1000i
 Auto Top Up Unit D-D Compact ATO D-D Compact ATO D-D Compact ATO D-D Compact ATO D-D Compact ATO
 Water Circulation 2 x Jecod SOW 4 2 x Jecod SOW 4 / 8 2 x Jecod SOW 8 / 15 2 x Jecod SOW 15 2 / 3 x Jecod SOW 15
 Jumpguard Aquarium Mesh Cover TC7575PRO TC12075PRO TC12075PRO TC18090PRO TC18090PRO
 UV Steriliser Deltec 10W Deltec 10W Deltec 20W Deltec 20W / 39W Deltec 39W
 Dosing Pump H2Ocean Pro 4 Channel H2Ocean Pro 4 Channel H2Ocean Pro 4 Channel H2Ocean Pro 4 Channel H2Ocean Pro 4 Channel

Recommended Lighting   Fish Only Soft Coral Reef Mixed Reef SPS Dominant Reef
Aqua-Pro Reef 600 CUBE  Lights Prime 16HD Reef Prime 16HD Reef Hydra 32HD Hydra 64HD
Mounting Option Prime Flex Mount 18" Prime Flex Mount 18" HTMG2 Bracket HTMG2 Bracket

Aqua-Pro Reef 900  Lights 2 x Prime 16HD Reef 2 x Prime 16HD Reef 2 x Hydra 32HD 2 x Hydra 32HD
Mounting Option 2 x Prime Flex Mount 12" 2 x Prime Flex Mount 12" 2 x HTMG2 Bracket 2 x HTMG2 Bracket

Aqua-Pro Reef 1200  Lights 2 x Prime 16HD Reef 3 x Prime 16HD Reef 2 x Hydra 32HD 2 x Hydra 64HD
Mounting Option 2 x Prime Flex Mount 18" 3 x Prime Flex Mount 18" 2 x HTMG2 Bracket 2 x HTMG2 Bracket

Aqua-Pro Reef 1500  Lights 3 x Prime 16HD Reef 3 x Prime 16HD Reef 3 x Hydra 32HD 3 x Hydra 64HD
Mounting Option 3 x Prime Flex Mount 18" 3 x Prime Flex Mount 18" 3 x HTMG2 Bracket 3 x HTMG2 Bracket

Aqua-Pro Reef 1800  Lights 4 x Prime 16HD Reef 4 x Prime 16HD Reef 4 x Hydra 32HD 4 x Hydra 64HD
Mounting Option 4 x Prime Flex Mount 18" 4 x Prime Flex Mount 18" 4 x HTMG2 Bracket 4 x HTMG2 Bracket

Premium Cabinet Colour Finishes

Ultra Gloss White

Ultra Gloss Black

Ultra Gloss Anthracite

Matt Anthracite

Standard Cabinet Colour Finishes

Drift Wood Concrete

Carbon Oak

Satin Black

Platinum Oak

Natural Oak

Tobacco Oak

Ultra Gloss Japanese Pear
